1.Can travel at slow speed and rapid speed self propelled.
2.Only one person is needed to lower, raise, forward, backward, steer the machine. It improves working efficiency and reduces man-power and labor intensity greatly.
3.Safe ground clearance for indoor/outdoor Operation.
4. Robust, reliable and easy to maintain.
5. Slope alarm, charger indicator.
6.Pit protection system for max. Safety, Flexible turning unit.
7.It is especially good for long time work at airport terminals, stations, docks, shopping markets, stadiums and work shops.
| Product List | ||||||
| Model | Platform size | Load capacity | Net lifting height | Overall dimensions | Table extension | Machine weight |
| GTJZ-6 | 2.26*1.13m | 550kgs | 6m | 2.475*1.15*2.158 | 0.9m | 2060kgs |
| GTJZ-8 | 2.26*1.13m | 450kgs | 8m | 2.475*1.15*2.286 | 0.9m | 2190kgs |
| GTJZ-10 | 2.26*1.13m | 320kgs | 10m | 2.475*1.15*2.414 | 0.9m | 2430kgs |
| GTJZ-12 | 2.26*1.13m | 320kgs | 11.8m | 2.475*1.15*2.542 | 0.9m | 2960kgs |
| GTJZ-14 | 2.64*1.13m | 227kgs | 13.8m | 2.84*1.39*2.59 | 0.9m | 3320kgs |
CONVENIENT DESIGN
1. The self-propelled scissor lift can be operated and moved on the platform under the lifting state, which is more convenient and flexible for operation and use.
2. Extendable platform can be quickly spread out to the working point.
3. Foldable guardrail reduces the space occupation of the whole machine.
4. The minimum turning radius (0m inside the wheel) and compact design make it easy to operate in a small space.
5. 25% climbing ability, able to climb slope smoothly.
6. Rotary chassis for easy maintenance.
7. Fault code display automatically for convenient maintenance.
